labwork JPL4400 Adjustable Outboard Jack Plate, 4-Inch Setback and Vertical Adjustment for 40-225 HP Boats

Product Description

Improve outboard positioning and setup flexibility with this factory-style adjustable jack plate. Constructed from polished aircraft-grade aluminum, it provides 4 inches of vertical adjustment and 4 inches of setback for compatible boats powered by 40-225 HP outboard motors.

Compatibility

• Compatible with boats using 40-225 HP outboard motors
• Maximum rated horsepower: 225 HP
• Not suitable for boats or motors below the specified application range

Specifications

• Type: Adjustable Outboard Jack Plate
• Model: JPL4400
• Material: Polished Aircraft-Grade Aluminum
• Color: Silver
• Vertical Adjustment: 4 in
• Setback: 4 in
• Weight: 24 lb
• Maximum Horsepower: 225 HP
• Adjustment: Single Steel Bolt
• Mounting Holes: Pre-Drilled for 1/2-Inch Stainless Hardware
• Top Hole Spacing: 12-7/8 in center-to-center
• Bottom Hole Spacing: 9-7/8 in center-to-center
• Vertical Hole Spacing: 8 in
• Hardware: Bronze and Brass Hardware Components

Features

• High-strength polished aluminum construction
• Single-bolt adjustment for convenient setup
• Provides 4 inches of vertical movement
• Provides 4 inches of setback
• Bronze and brass components help reduce binding
• Pre-drilled mounting holes support easier installation
• Factory-style design for compatible outboard boat applications

Package Includes

• 1 × Adjustable Outboard Jack Plate

Important Note

Verify the boat transom dimensions, mounting-hole spacing, outboard horsepower, weight, and required hardware before ordering. The product is not intended for boats below the listed 40 HP application range. Professional marine installation is recommended.
